48V lithium battery 100ah 200ah lifepo4 battery pack
The 51.2V LiFePO₄ Modular Battery Series is a high-performance energy storage solution designed for residential, commercial, and telecom applications. Built with brand-new Grade A lithium iron phosphate cells and integrated with an advanced Battery Management System (BMS), this battery ensures superior safety, long service life, and easy installation.
Whether you're upgrading an existing energy system or starting a new setup, this modular battery delivers reliable power—perfect for off-grid environments and locations with unstable grid connectivity.
Specification :
| Model | SM24-100 | SM24-150 | SM24-200 | SM48-50 | SM48-100 | SM48-150 |
| Energy | 2560Wh | 3840Wh | 5120Wh | 2400Wh | 4800Wh | 7200Wh |
| Nominal Voltage (V) | 25.6V | 25.6V | 25.6V | 48V | 48V | 48v |
| Rated Capacity (Ah) | 100Ah | 150Ah | 200Ah | 50Ah | 100Ah | 150Ah |
| Chemistry | Lithium Iron Phosphate (LiFePo4) |
| Design Life | More than 10 years |
| Cycle Life | More than 3500 cycles at 80% DOD. |
| Communication Protocol | CAN , RS485 , RS232 |
| Display | LED Display Optional |
| Internal Impedance | 50 mΩ |
| Max. Charging Current | 50A | 80A | 100A | 50A | 100A | 100A |
| Max. Continue Discharging Current | 80A | 100A | 100A | 70A | 100A | 100A |
| Battery Dimensions (MM) | 438*375*133mm | 442*400*177mm | 442*400*177mm | 438*375*133mm | 442*400*177mm | 442*400*177mm |
| Weight | Approx: 40kg | Approx: 58kg | Approx: 70kg | Approx: 40kg | Approx: 70kg | Approx: 80kg |
| Battery Protection | Over-charge &Over discharge protection , over current protection ,over temperature production , short-circuit products , cells balance |
| Outer Package Material | Black Power Coated steel case (battery rack or cabinet is optional) |
| Operating Temperature | Charging: 0 to +50℃ Discharging: -20 to +60℃ Storage: -20 to +60℃ |
